VLX 500 Sliding Window

VLX 500 Sliding Window in Fort Worth, TX | Meridian Windows and Doors Fort Worth

The VLX 500 Sliding Window is a high-performance aluminum sliding system built for homeowners in Fort Worth who want expansive glass, clean sightlines, and a mechanism that glides without friction year after year. This is the window you choose when you’re tired of vinyl frames that bow in the Texas heat and tracks that jam with dust. Available in 2-track and 3-track configurations, it suits everything from a compact bathroom opening to a full wall of glass overlooking a backyard patio. Meridian Windows and Doors Fort Worth is an authorized ViewLux installation partner, which means we sell this product at partner pricing, install it to warranty-safe specifications, and stand behind the finished result. Call (682) 708-0962 to schedule a free measurement.

Call (682) 708-0962

Product Overview – VLX 500 Sliding Window

The VLX 500 was designed around one core idea: a sliding window should feel effortless. The frame is engineered from extruded aluminum with a wall thickness of 0.079 inches, which gives it structural rigidity that vinyl simply can’t match at the same profile width. At 1.97 inches wide, the frame stays slim enough to preserve maximum glass area while carrying the load of large panes without flexing. The result is a window that opens with one or two fingers, even when the sash spans several feet.

Architecturally, this series fits two distinct Fort Worth aesthetics. In modern builds around West 7th, Arlington Heights, and the Near Southside, homeowners pair the slimmer profile with dark finishes to create that sharp, industrial look. In more traditional neighborhoods like Ridglea Hills or Tanglewood, we’ve installed the VLX 500 in softer tones like Champagne and Teak Wood, where it reads as a refined upgrade rather than an architectural statement piece. The 2-track configuration works well for standard openings, while the 3-track version gives you a wider clear opening when the window is fully open, ideal for capturing cross-breezes in spring before the Fort Worth summer sets in.

Part of why buyers choose this series over cheaper imports is durability. The aluminum doesn’t absorb moisture, so it won’t swell, warp, or rot during Fort Worth’s humid stretches in May and October. The powder-coated finishes resist chalking under direct sun, which matters when your west-facing windows catch the full afternoon heat from July through September. And because the tracks are precision-machined, dust and grit that blows through during dry spells doesn’t grind the rollers down the way it does on economy sliders. This is a window you install once and stop thinking about.

Technical Specifications

• Frame material: Extruded aluminum with 0.079″ wall thickness
• Profile width: 1.97″ frame depth, engineered for slim sightlines with structural integrity
• Track configurations: 2-track (standard) and 3-track (wider clear opening)
• Glass options: Clear, Frosted, Low-E, Tempered, Laminated (impact-resistant available)
• Finish options: Premium Black, Pure White, Anodized Silver, Bronze, Champagne, Teak Wood
• Screen options: Retractable screen or standard sliding screen
• Performance: Thermally broken frame with NFRC-rated energy performance
• Installation standard: AAMA 2400/2410 compliant, AAMA 812 foam perimeter seal
• Ratings: Airtightness, water penetration resistance, and sound transmission class ratings certified for the Fort Worth climate zone

Performance Features

Thermal Efficiency

The VLX 500 uses thermal break technology that separates the interior and exterior aluminum faces, cutting heat transfer through the frame itself. Combined with Low-E glass, this window holds an NFRC rating that reflects real performance in Fort Worth’s climate zone, where cooling costs dominate most of the year. In practice, you’ll feel the difference on a July afternoon when you touch the interior frame and it’s not radiating heat.

Acoustic Performance

If you live near I-30, Chisholm Trail Parkway, or the rail lines that cut through the city, sound control matters. The VLX 500’s frame tolerances and glass pairing options reduce exterior noise measurably. Laminated glass adds another layer of sound dampening for homes in high-traffic corridors like Camp Bowie or Rosedale, where road noise is a constant companion.

Airtightness & Weather Seal

The frame’s interlocking sashes and continuous weatherstripping create a tight seal against air infiltration. During Fort Worth’s windy stretches in March and November, a properly sealed window keeps conditioned air inside where it belongs. This is where the AAMA compliance becomes practical: the window is tested to prevent air leaks that show up as drafts around the sash perimeter.

Waterproofing

Fort Worth sees sudden downpours, and windows take the brunt of wind-driven rain from spring storm systems. The VLX 500’s weep system channels water away from the interior, while the thermally broken frame prevents condensation from forming on interior surfaces. When paired with an AAMA 812 foam sealant at the perimeter during installation, the assembly resists the water intrusion that leads to mold and sill rot in older homes.

Wind Resistance

Aluminum frames carry higher wind-load ratings than vinyl, which matters in a region where severe storms roll through with straight-line winds. The VLX 500 is wind-load rated for local climate requirements, so large openings on second-story walls or exposed elevations don’t require custom engineering to meet code in Fort Worth.

Security & Hardware

The hardware on this series is built into the frame rather than surface-mounted, which keeps the clean profile intact while providing a positive locking action. Laminated glass is available as an upgrade, adding impact resistance and shatter retention. For ground-floor applications in neighborhoods where security is a concern, that glass upgrade is worth considering.

Color & Glass Options

The VLX 500 comes in six finishes, and we’ve seen each one work in different Fort Worth contexts. Premium Black is the most requested finish for modern builds and renovations in the Fairmount and Magnolia areas, where black windows have become the standard for new construction. Pure White stays classic in traditional brick ranch homes. Anodized Silver reads clean and commercial, and it’s a strong choice for mid-century homes that originally shipped with aluminum windows. Bronze is darker than Silver but softer than Black, working well on homes with warm brick tones. Champagne and Teak Wood are the wildcards: they lean warm and organic, and they’ve become popular in Tanglewood and Ridglea Hills where homeowners want something distinct without going full modern.

On glass, Clear is the budget pick for windows that face a shaded porch or a tree line. Frosted works for bathrooms, utility rooms, and any opening where privacy matters more than the view. Low-E is the upgrade we recommend to almost every Fort Worth customer because it cuts solar heat gain during the long cooling season. Tempered glass meets code requirements for windows near doors, in bathrooms, and in stairwells. Laminated glass adds both impact resistance and sound reduction, and it’s the choice for homes near high-traffic roads or in areas where storm debris is a concern.

Installation by Meridian Windows and Doors Fort Worth in Fort Worth

A high-performance window underperforms if it’s installed poorly. We have replaced windows in Fort Worth homes where the previous installation was so far out of square that the sashes bound and the locks never lined up. That isn’t a product problem; it’s an installation problem. Our crews do this work daily, not as a side service.

We start with a pre-install inspection of the rough opening. Fort Worth homes run the full range: pier-and-beam bungalows in Mistletoe Heights that have settled for 80 years, slab-on-grade builds from the 1990s with framing that’s surprisingly straight, and new construction where everything is fresh. Each opening gets measured for level, plumb, and square before any window leaves the truck. If the rough opening is off, we correct it before setting the frame. If the old window leaked, we investigate the flashing and sheathing before the new unit goes in.

Our installation method follows AAMA 2400/2410 standards. The window is set level, plumb, and square in the opening, shimmed at the load points, and fastened through the frame according to manufacturer specifications. We apply AAMA 812-rated low-expansion foam sealant around the full perimeter, which does three jobs: it seals air movement, blocks water paths, and insulates the gap between frame and framing. The foam is trimmed and the interior is finished cleanly. We then install the exterior sealant and run a water test on the opening to confirm the drain path works. Cleanup includes removing every scrap of old calking, foam trimmings, and packaging from the property.

We stress all of this because a botched DIY or handyman install voids the manufacturer warranty on the VLX 500. ViewLux warranties cover defects in materials and workmanship in the product, not failures caused by improper installation. When Meridian Windows and Doors Fort Worth installs the window, the workmanship is our responsibility and the product warranty stays intact. For Fort Worth specifically, our installation methods account for the expansion and contraction cycles that come with 30-degree winter mornings and 105-degree summer afternoons. That movement is real, and the foam perimeter seal plus proper flashing detail is what prevents it from becoming a leak path ten years down the road.

Frequently Asked Questions – VLX 500 Sliding Window

What is the lead time for the VLX 500 Sliding Window?
Lead time varies by configuration, finish, and glass package, but most VLX 500 orders arrive at our Fort Worth warehouse within 2 to 4 weeks of final measurement and order confirmation. Custom sizes, laminated glass, and less common finishes like Champagne or Teak Wood add time to production. We lock in pricing at order and provide a written timeline before any deposit is collected. Call (682) 708-0962 to check current lead times for your specific configuration.

Does the VLX 500 qualify for energy tax credits?
Yes, in many cases. The VLX 500 with Low-E glass meets or exceeds the ENERGY STAR performance thresholds for windows in the South-Central climate zone, which covers Fort Worth, and may qualify for federal energy tax credits. The credit is tied to the product’s NFRC ratings, so the exact glass package matters. We can show you the certification labels for your chosen configuration during the estimate so you know exactly what you qualify for before you buy. Call (682) 708-0962 and we’ll help you sort through the credit details.

What warranty comes with the VLX 500 Sliding Window?
The VLX 500 carries a manufacturer warranty from ViewLux covering defects in materials and workmanship, including the frame, glass seal integrity, and hardware under normal residential use. The warranty remains valid only when the window is installed by an authorized partner following AAMA installation standards. As an authorized ViewLux installation partner in Fort Worth, Meridian Windows and Doors Fort Worth installs to those standards, and our labor comes with a separate workmanship warranty. We’ll put both in writing before you sign anything.

Can I customize the size of the VLX 500 Sliding Window?
Yes. The VLX 500 is built to your opening dimensions, not pulled from a stock size chart. During your free on-site measurement, we measure every opening to the eighth of an inch and note any framing issues that need correction before ordering. Two-track and three-track configurations give you additional flexibility in how wide the clear opening is when the window is fully open. For oversized openings, we verify wind-load requirements against Fort Worth building code before finalizing the order.

How do I maintain aluminum frames on the VLX 500?
Aluminum frames need almost nothing beyond occasional cleaning. Wipe the frames and glass with a mild soap-and-water solution twice a year, and keep the bottom track clear of dirt and debris so the rollers run freely. Fort Worth’s dry seasons bring dust that can accumulate in the track; a quick vacuum or brush-out fixes that in minutes. The roller assemblies are serviceable, and if a roller wears out after years of use, it can be replaced without replacing the entire sash. No painting, no sealing, no rot repair. That’s the point of aluminum.

Get a Quote – VLX 500 Sliding Window in Fort Worth

If you’re pricing the VLX 500 for one window or twenty, start with a free on-site measurement. We’ll walk the project with you, check rough openings, confirm your glass and finish selections, and give you a written line-item quote with no change orders down the road. Call Meridian Windows and Doors Fort Worth at (682) 708-0962 to schedule your appointment. We serve all of Fort Worth and the surrounding metro, and we’re happy to show you sample frames and finishes at our showroom before you decide.

Written by the team at Meridian Windows and Doors Fort Worth, authorized ViewLux installation partner serving Fort Worth and the surrounding metro.
